Description
This is a 3 Ton 208/230 Volts 1-Phase Direct Factory Replacement Compressor (Copeland) Model CR38K6-PFV-875. This is Copeland's recommended replacement for old Copeland Model #s YRB2-0300-PFV & YRB2-0301-PFV. It is rated at 38,000 BTU.Thanks for looking and good luck!. Thanks for looking and good luck!
TECHNICAL SPECIFICATIONS
Tonnage: 3
Volts 60 Hz 208/230-1.
Phase 1.
Refrigerant Type R-22.
Line Connection Suction ID (In) 3/4 .
Line Connection Discharge ID (In) 3/8.
Base Mounting Centers (In) 7 1/2 x 7 1/2.
Height (In) 14 13/16.
Width (In) 9.
Length (In) 9 7/16.
Run Amps@BtuH 17.4.
Application OEM A/C Equipments.
Includes Crankcase Heater.
Run Capacitor is 40uf 440 volt. Most condensing unit capacitors are dual capacitors, meaning they operate the compressor and the fan. To purchase the correct capacitor you will need to know the uf rating on the fan.<>
Start Capacitor. 189-227 330 Volt
To install a Compressor PROPERLY you need to have AND use the proper equipment and use proper installation technique. If you are not familiar with these techniques or you do not have the proper equipment then you SHOULD have a qualified HVAC tech to install your new compressor. All Sales are Final! There are NO WARRANTIES! Compressors Should be installed by a qualified Heating Air Conditioning Tech.
TECHNICAL SPECIFICATIONS
Tonnage: 3
Volts 60 Hz 208/230-1.
Phase 1.
Refrigerant Type R-22.
Line Connection Suction ID (In) 3/4 .
Line Connection Discharge ID (In) 3/8.
Base Mounting Centers (In) 7 1/2 x 7 1/2.
Height (In) 14 13/16.
Width (In) 9.
Length (In) 9 7/16.
Run Amps@BtuH 17.4.
Application OEM A/C Equipments.
Includes Crankcase Heater.
Run Capacitor is 40uf 440 volt. Most condensing unit capacitors are dual capacitors, meaning they operate the compressor and the fan. To purchase the correct capacitor you will need to know the uf rating on the fan.<>
Start Capacitor. 189-227 330 Volt
To install a Compressor PROPERLY you need to have AND use the proper equipment and use proper installation technique. If you are not familiar with these techniques or you do not have the proper equipment then you SHOULD have a qualified HVAC tech to install your new compressor. All Sales are Final! There are NO WARRANTIES! Compressors Should be installed by a qualified Heating Air Conditioning Tech.
Function:
Compressors compress refrigerants (freon) from a gas state into a liquid state and then pump it through the freon lines.
Replaces Old Part #s:
Repair Difficulty Level:
Partial List of Units that Use This Item:
Hit Ctrl+F and enter your model number for a quick search!
