Description
This is a BRAND NEW-In-The-BOX Universal Furnace Relay with a 24 volt coil. It has two completely independant circuits with 2 seperate "Feed" terminals 2 "Normally Open" set of contacts and 2 "Normally Closed" set of contacts. Replaces Rheem/Ruud/Weather King/Corsaire part #s R8222V 1003 R8222V1003 R8222N1011 & R8222N 1011. Thanks for looking and good luck!
Function:
Relays are switches that open and close circuits electrically. In most HVAC equipment a low voltage coil relay (24 vac) is energized in order to open or close a higher voltage (usually 120-240) circuit.
Replaces Old Part #s:
R8222V 1003 R8222V1003 R8222N1011 R8222N 1011
Repair Difficulty Level:
Partial List of Units that Use This Item:
Hit Ctrl+F and enter your model number for a quick search!
